Technical parameters

Model

HMS-16/25/32/63

Rated insulation voltage

Ui

V

1500

Rated heating current

Ithe

A

16/25/32/63

Rated impulse withstand voltage

Uimp

V

8000

Rated short-time withstand current(1s)

Icw

2,4

A

1000

2H

A

1700

Rated short-circuit making capacity

Icm

2,4

A

1000

2H

A

1700

Rated short-circuit current

Icc

A

5000

Mechanical life

10000

DC poles

2 or 4

Operating temperature

℃

-25 to +70

Storage temperature

℃

-40 to +70

Class of pollution

2

IP level

IP66
